Cub Cadet HDS 2205 14A-2D7-603 (2008) Engine accessories Ricambi

Engine accessories 14A-2D7-603 (2008)

Cub Cadet Garden tractors HDS 2205 14A-2D7-603 (2008) Engine accessories
PosizioneArticolo numeroDescrizione
1 629-04158AHARNESS ASM-MAIN
2 703-05875CSHIELD-MUFFLER HEAT
3 703-05883SHIELD-PTO CLUTCH
4 710-0192SCR:MACH:#10-24:0.375:TRUSPHI
5 Cub Cadet HHCS:3/8-24:1.75:GR5:STD710-0539HHCS:3/8-24:1.75:GR5:STD
6 Cub Cadet SCREW:TT:1/4-20:0.375:HXINDWSH710-0653SCREW:TT:1/4-20:0.375:HXINDWSH
7 Cub Cadet SCRE.HHCS:7/16-20:1.50:GR5:STD710-0757SCRE.HHCS:7/16-20:1.50:GR5:STD
8 710-3119BOLT-HEX PATCH 3/8-16 X .75 GR
9 710-3209HHCS:M6-1.0:10MM:GR8.8:STD
10 711-1083ROD
11 712-3005NUT:FLGLK:3/8-16:GR5
12 712-3054NUT-HEX LOCK
13 717-04326CLUTCH-ELEC
14 725-0157CBL:TIE: 3/16 X .05 X 7.4
15 Cub Cadet CLAMP HOSE: .490 DIA726-0205CLAMP HOSE: .490 DIA
16 728-0177POP RIVETS
17 Cub Cadet SPRING WASHER .401 x.870 x.063736-0105SPRING WASHER .401 x.870 x.063
18 Cub Cadet WASHER:LOCK:7/16:REGULAR DUTY736-0171WASHER:LOCK:7/16:REGULAR DUTY
19 736-0400WASH:FLAT:.194 x .62 x .063
20 736-3082AWASH:FLAT:.450 IDX1.5 ODX .172
21 737-0199PIPE:STRAIGHT:3/8 NPT x 2.0 LG
22 737-0269OIL:MOTOR:SAE 10 W 30
23 737-0272ELBOW-3/8
24 746-04277CHOKE CABLE
25 Cub Cadet CBL:THROT:38,0" LG x 1,62 EXT746-1100CBL:THROT:38,0" LG x 1,62 EXT
26 750-3356SPACER-PULLEY
27 751-10249AEXHAUST
28 751-10349HOSE:FUEL:LOW PERMEATION
29 751-10517DRAIN:OIL
