CRAFTSMAN TRACTOR 247.203760 Ricambi
247.203760 TRACTOR
| Posizione | Articolo numero | Descrizione | |
| 1 |  | 617-04094 | GEAR ASSM |
| 2 |  | 710-0514 | HEX BOLT |
| 3 |  | 710-0643 | VITE |
| 4 |  | 710-1309 | SCREW-PAN HE |
| 5 |  | 710-3180 | BOLT HEX |
| 6 | 912-0214 | NUT-HEX INS | |
| 7 | 912-0240 | NUT-JAM 7/16 | |
| 8 |  | 712-04063 | DADO |
| 9 | 912-0431 | NUT-HEX LOCK | |
| 10 | 923-0448A | JOINT ASSY-L | |
| 11 |  | 736-0242 | RONDELLA |
| 12 |  | 736-0331 | BELL-WASH |
| 13 | 931-0484A | HUB CAP | |
| 14 |  | 738-04141 | VITE |
| 15 | 938-05078 | STEER SHAFT | |
| 16 |  | 741-04124 | CUSCINETTO |
| 17 | 747-06252A | LINK:DRAG | |
| 18 | 948-0389 | CALOTTA | |
