Snapper 7082797 - TA520 Tiller Attachment Tine Group Ricambi

Tine Group 7082797 - Snapper TA520 Tiller Attachment

Snapper Zubehör, Fräsen und Kultivierer 7082797 - Snapper TA520 Tiller Attachment Tine Group
PosizioneArticolo numeroDescrizione
1 BS7036158YPSTABILIZER, CENTER
2 BS703300PIN, 3/32 X 1.6
3 BS7027198YP(C) HFLB, 3/8C X1 YZ
4 BS7091587SMUNTERLAGSCHEIBE, .531X1.062X.1
5 BS7018791YPPIN, STABILZER
6 BS703930WASHER, INT LCK, 3/8
7 BS7038224
8 BS703333MUTTER, 3/8-16
9 BS1726317SMGRIP, FOAM
10 BS7038228
11 BS7011035YPACHSBOLZEN LINKS
12 BS703459NUT, HEX, 5/16-24
13 BS7091516SMSPLINT, 5/32X1 YZ
14 BS7047879
15 BS27655
16 BS7021983YPLINKAGE, LIFT
17 BS7047878
18 BS7015332YPPIN, LIFT ##
19 BS7015334
20 BS36156
21 BS7090918YPHHCS, 3/4F X3 GR2 ZP
22 BS9357MASCHRAUBE, 5/16-18X .75WD
23 BS7012802SM
24 BS47880
25 BS36157
26 BS7035096YPFRAME, MAIN
27 BS7091588SMBUNDSCHRAUBE, 3/8C X3/4 GR5 Y
28 Snapper MUTTER, 5/16-18, GR5BS703409MUTTER, 5/16-18, GR5
29 BS7015335YPSPRING, DRAFT CONTROL
30 BS7015336YPSPRING, LIFT ASSIST
31 BS7012844
32 BS32487
33 BS7032489YPBRKT, DRAFT CONTROL
34 BS7057434YPSTRAP ASSY.
35 BS7090283YPHJN, 3/4F ZP
36 BS7032505
37 BS7090645
38 BS7091619
39 BS7090661YPHFLB, 5/16C X1 ZP
40 BS7090815YPSCHRAUBE, 3/8-16 X 3/4
