Trennschneider, Cut-Off FUEL TANK Ricambi

• Start
• Trennschneider, Cut-Off
• K1250 Rail, 2010-02
• FUEL TANK

FUEL TANK K1250 Rail, 2010-02

Posizione		Articolo numero	Descrizione
1		506 28 98-01	KABEL
2		503 14 21-06	TANK
3		503 14 08-01	BUCHSE
4		503 57 76-02	SCHLAUCH
5		504 35 72-01	BENZINFILTER F.M-510
6		501 76 83-04	BENZINSCHLAUCH
7		506 29 39-01	TANKENTLUEFTUNG
8		720 12 78-06	STIFT 4X35
9		720 12 40-20	STIFT
10		503 13 16-01	HEBEL
11		503 13 18-01	FEDER
12		503 13 36-01	GASHEBEL
13		503 14 23-01	GASSPERRE,SATZ
14		506 23 34-01	SCHUTZ
15		503 21 45-16	SCHRAUBE
16		503 13 26-01	VIBRATIONSDAEMPFER
17		506 26 41-11	BENZINFILTER
18		506 27 11-01	GEWICHT
19		506 26 41-01	FILTER
20		503 20 02-25	SCHRAUBE
21		503 13 27-01	VIBRATIONSDAEMPFER
22		503 13 25-01	VIBRATIONSELEMENT
23		725 53 68-55	SCHRAUBE
24		506 25 59-03	TANKDECKEL KPL.
25		506 29 21-01	DICHTUNG
26		503 57 89-01	HALTER
27		501814701	501814701
28		503 20 02-12	SCHRAUBE
29		503 14 05-01	PLATTE
30		503 20 02-30	SCHRAUBE
