Yard-Man X 604 G 13AX604G643 (2002) Lifting mecanism, Seat, Fender Ricambi

SPRING-EXTENSION

Articolo numero:
732-0874
Posizione:
12
Modell Year:
X 604 G / 2002 SLX 117 S / 2002 Sprint SLX 117 S / 2001
DINNORM:
SPEC 701-01006 OR 701-01000
7.70 €
Tutti i prezzi includono l'IVA nell'UE, in più spedizione
Quantità:
Dettagli di contatto Sicurezza del prodotto
Articolo aggiunto al carrello1
in magazzino in magazzino
Yard-Man Lawn tractors X 604 G 13AX604G643 (2002) Lifting mecanism, Seat, Fender
PosizioneArticolo numeroDescrizione
1 747-1130ROD-DECK FRONT ADJUST
2 683-0197LIFT SHAFT ASSY.
3 Yard-Man PIN:CLV:.50 DIA x.78 LG711-0332PIN:CLV:.50 DIA x.78 LG
4 Yard-Man NUT:HEX:1/2-13:GR5712-0206NUT:HEX:1/2-13:GR5
5 Yard-Man NUT:FLGLK:3/8-16:GRF:TOP LK712-0431NUT:FLGLK:3/8-16:GRF:TOP LK
6 Yard-Man NUT:FLGLK:5/16-18:GR5:SD LK712-3004ANUT:FLGLK:5/16-18:GR5:SD LK
7 Yard-Man NUT:HEXLK:1/2-13:GRB:NYLON712-3083NUT:HEXLK:1/2-13:GRB:NYLON
8 Yard-Man PIN:COT:.072 DIA x 1.13 LG714-0104PIN:COT:.072 DIA x 1.13 LG
9 Yard-Man PIN:CLICK:.092 x 1.64 LG714-0145PIN:CLICK:.092 x 1.64 LG
10 716-0106E-RING:.625 DIA. SHAFT
11 Yard-Man GRIP-HANDLE:1/2720-0311GRIP-HANDLE:1/2
12 732-0874SPRING-EXTENSION
13 Yard-Man SPR:EXTN:1.15 OD x 5.99 LG732-0934SPR:EXTN:1.15 OD x 5.99 LG
14 736-0275WASH:FLAT:.344 x .688 x.065
15 736-0921WASHER:LOCK:1/2:REGULAR DUTY
16 736-3019WASHER:FLAT:.531x1.062x.134:HD
17 Yard-Man WASH:THRST:.510 X 1.120 X .060736-3084WASH:THRST:.510 X 1.120 X .060
18 738-0138SCR:SHLDR:.437 X .470 LONG
19 738-0143SCR:SHLDR:.496x.336:3/8-16
20 Yard-Man BRG:HEX FLNG741-0225BRG:HEX FLNG
21 741-0715FLANGE BEARING
22 Yard-Man CBL:LIFT:16.16 LG746-0968CBL:LIFT:16.16 LG
23 747-1111LINK:LIFT:CROSSBAR
24 756-1154PULLEY DECK RECRUITMENT
25 783-0678Lifting arm
26 783-0720ABRKT:ADJ:FRT DECK ROD
27 710-0260BOLT-CARRIAGE
28 Yard-Man SCREW:TT:5/16-18:0.625HXINDWSH710-0604ASCREW:TT:5/16-18:0.625HXINDWSH
29 Yard-Man SCR:HL:1/4-15:0.750:HXINDWSH710-0895SCR:HL:1/4-15:0.750:HXINDWSH
30 731-1990COVER-LIFT LEVER
31 731-2104ACOVER-SHIFT LEVER
32 738-0155BOLT:SHLDR:.435 x.160:5/16-18
33 783-0677BRACKET-LIFT-ADJUSTMENT
34 783-0685AFENDER
35 783-0715BRACKET
36 710-1268HEX. SCREW:B:#10-16:0.375
37 Yard-Man NUT:FLGLK:1/4-20:GRF712-3027NUT:FLGLK:1/4-20:GRF
38 720-0309AGRIP:SEAT:ADJUSTER
39 731-1989SPACER:SEAT:ADJUSTER
40 732-0499COMPR. SPRING .41 OD X 1.50 LG
41 736-0175SPRING WASHER:.265 x.562 x.025
42 736-0204WASH:FLAT:.344 X .620 X .033
43 738-0137ASCR:SHLDR:.340X.285:1/4-20
44 738-1007SHOULDER SCREW
45 783-0611STOP:SEAT:ADJ
46 783-0738BRACKET-SEAT PIVOT
47 783-0739LEVER-SEAT ADJUSTMENT
48 783-0753SELCT:SEAT:ADJ
49 757-0365ASEAT:V-480:MED BACK YELLOW
49A 757-0372SEAT:V560 RAD YELLOW
49B 757-0350SEAT:PL HIGH BACK W/DRAIN BLK
50 735-0657PAD-FOOT LH
51 735-0656PAD-FOOT RH
51A Yard-Man MOUNTING CLIP:.250 DIA726-3046MOUNTING CLIP:.250 DIA
52 Yard-Man COTTER PIN 3/32 DIA X 1.00714-0111COTTER PIN 3/32 DIA X 1.00
53 783-0891ABRACKET, HITCH ARM MT.
